| 1/3 CMOS |
Resolution 2560*1440 |
Fixed lens 2.8mm |
Thermal imaging detector | VOx micro-bolometer |
R Response band 8-14μm |
Resolution 256*192 |
Pixel spacing12μm |
NETD≤40mk(25°C,F1.0) |
Lens 3.5mm，field angle 50°*37.2° |
Measuring Range -20°C-150°C与0°C-550°C two gear, maximum accuracy : ±2°C (within 8 meters), remote accuracy :±8° or 2% of the
reading value (take the maximum) |
UV sensor | the detection Angle can be up to 120°, and the detection distance can be up to 20 meters |
Audio and video parameters |
Visible light resolution | main stream:2560*1440, 1920*1080, 1280*720
substream:704*576, 960*544, 640*360, 320*184 |
Thermal imaging resolution | main stream:704*576
Substream: 704*576 |
video compression | H.265/H.264 BP/MP/HP |
Rate range | 30Kbps～16Mbpsadjustable, support CBR/VBR |
Audio format | G.711A, G.711U, AAC |
Image Settings | Visible light: Contrast/sharpness/brightness/saturation
Thermal imaging: Contrast/sharpness/brightness
Hue: White hot/Iron red/Black hot/Rainbow/Red hot/Green hot/Fusion mode |
Wide Dynamic | Linear mode, WDR mode |
Strong light inhibition | support |
Backlight compensation | support |
White balance | Support automatic and manual modes |
Title Overlay | Support custom title, channel name, date and time, and adjustable superposition |
Noise reduction | 2D and 3D noise reduction |
Day-night mode | Support time switching and image detection switching |
Night visual range | Infrared light 30m, warm light 10m |
Intelligent function |
UV spectral flame detection | Open flame/low temperature flame/light flame/electric spark |
Temperature measurement | Real-time full screen temperature measurement, highest temperature, lowest temperature, average temperature |
Support custom 20 points, lines, surfaces and areas of temperature measurement, support visible light channel mapping display
temperature |
Heat surge | The trend change of temperature suddenly rising in the detected area is recorded to produce early warning signal of fire. |
Fire smoke detection | Smoke and flame identification |
Behavioural analysis | Human tripwire intrusion, human zone intrusion, motion detection |
Action with alarm | Alarm voice, linkage light, IO alarm output, fire alarm light |
Network parameter |
WiFi/ Bluetooth module (standard) | Support Bluetooth 5.0, support WiFi6, working band 2.4GHz, 5GHz |
4G module (optional) | Support FDD-LTE/TDD-LTE, CAT 1, traffic rate:5Mbps/10Mbps |
Communication protocol | TCP/IP,UDP,RTP,RTSP,DNS,DHCP,FTP,NTP,PPPOE,SMTP |
Interface protocol | Support ONVIF、GB/T28181-2016,MQTT,HTTP |
Others |
Audio interface | 1 chanel audio input /1 chanel audio output, built-in MIC/ speaker |
I/O Alarm | 1 chanel alarm input /1 chanel alarm output |
Network interface | 1个RJ45 10M/100M Adaptive Ethernet port |
RS485 | Support |
SIM卡 | Support Nano card |
SD卡 | Max 512G Micro SD |
Reset | Support |
General parameter |
Operating temperature/humidity | -20℃ - +60℃/0% - 95% |
level of protection | IP66 |
power supply | Compatibility DC12V/DC24V,POE 802.3af/at |
Size of the machine | 158*99*52mm |
Weight of the machine | 740g (machine only) 1380g(with package) |
