AOP-PQ2821A
3MP+3MP+3MP 4G Camera With Power Plug
3*3MP 4G PT-Linkage Indoor/Outdoor use Camera with two way audio
Introduction
Specification
Accessories
Downloads
● Three cameras: Three cameras, the same screen three pictures.
●180° screen :180° ultra-wide screen, panoramic view.
● After the target is selected in the bullet video screen, the dome lens will automatically focus on the selected target.
● The linkage tracking: dome lens locks the moving object of the bullet and automatically tracks it.
● Intelligent application: human detection/human tracking
● Network connection: Support WiFi wireless connection/network cable /4G.
● Alarm notification: When a moving object is detected, the picture will be captured in time and the alarm will be pushed.
● Sound and light alarm: active defense, someone breaks into the warning area, equipment sound and light alarm.
● Video storage: MicroSD card (Max. 128GB)/ cloud storage
● Light control mode: infrared white light dual light design, support two night vision mode adjustable, to achieve full color at night.
● Two-way voice intercom: "built-in microphone and speaker, advanced compression algorithm to produce better sound quality, effectively reduce background noise. Can be with you anytime, anywhere
The family enjoy two-way live conversation (range 15 meters).
● Mobile phone monitoring: Support iOS and Android mobile phone client remote monitoring.
| Model Number | AOP-PQ2821A |
| Operating platform | Android/iOS |
| Number of online users | Three users view online data at the same time |
| Share users | Can share 100 users at the same time |
| Sensor | 1/3”CMOS Sensor |
| Pixel | 2304*1296@15fps |
| Minimum illumination color | Colors: 0.1 Lux,black/white: 0.01 Lux |
| WIFI | 802.11b/g/n;WEP,WPA,WPA2 encryption |
| 4G | European/North America/Asia Pacific |
| Humanoid detection | Humanoid detection, accurate filtering of invalid alarms |
| Humanoid tracking | Support |
| Gun-ball linkage | Precise linkage |
| Storage TF card | Supports a maximum of 128GB storage |
| Global cloud storage | Support |
| Night vision | Automatic night vision, full color mode, intelligent white light |
| Compression format | H.264 |
| Code rate | Main stream: 1920*1080,substream: 720x480(VGA) |
| Frame rate | 15fps |
| Image adjustment | Brightness, contrast, vertical, horizontal adjustable, OSD display |
| Built-in microphone | Support |
| Compression format | G.711 A-Law @16bits 8kbps |
| Speaker | Support |
| Key reset | Support |
| Alarm | Audible and visual alarm |
| The alarm sound can be customized | |
| Humanoid detection alarm | |
| Power supply | 12V/1.5A adaptor |
| Operating environment | -10℃~+60℃ |
