Image sensor

Sensor

4MP Progressive Scan CMOS

Max.resolution

2506x1294

Min.illumination

0.3LUX/F1.8

IR Control Mode

IR LED mode

Support

Night vision switching mode

Auto/manual

Video

Resolution

Main stream(2506x1294), sub-stream(640x360)

Video compression mode

H.265/H.264

Frame rate

15fps

Audio

Input

Passive MIC

Output

Built-in amplifier, direct connection to speaker

P2P

APP

TUYA, Hisee X

Network Protocol

Support TCP/IP, NTP, DHCP, UDP, P2P

Pan/Tilt

Motor interface

2 groups of motor interface，1 group: vertical，1 group: horizontal

Rotation angle

Tilt 60°，pan 355°

Functions

Motion detection

Support

AI humanoid shape

Support

Alarm notifications

Pushed by mobile phones

Storage

Support up to 128GB SD card

Local Storage

Recording standard

HD/SD available

Recording method

manual/alarm recording

Recording check

Support remote recording playback

Interface

WIFI

2.4G, IEEE802.11 b/g/n protocol, support WEP,WPA,WPA2 encryption

Wireless

Power interface

DC 5V

Others

Working temperature/humidity

-10℃ ~60℃，0%－90% RH

Power consumption

≤2W
